Description

A Class A or Class C LoRaWAN^® bridge converting wired sensors and transmitters into LoRaWAN^®-enabled wireless devices with near continuous monitoring and relay control.

• Works with any LoRaWAN-compliant network server
• Up to 6 miles RF range, LOS
• Internal antennaIP66/NEMA 4X Rated
• Remote and Local Configuration
• 12 to 24 Vdc external input power
• 4 to 24 Vdc to the sensor terminal
• -40°C to 80°C Operating Temperature
• Each VoBo XP has:
  • 7 Input channels; 3 analog, 2 digital, 1 interrupt, 1 RS485 (Modbus RTU)
  • 4 Load Driver outputs
  • Three sensors/transmitters per unit
  • Continuous monitoring in Class C mode
• Available with customer-defined pre-configuration
• Available with optional VoBoSync technology
• Available with optional VoBoAnalytics edge compute capability
• Available with optional multiple Modbus RTU read/write capability
• Hazardous Areas Certification
